Datasheet
Additional information
| Mounting Type | Through Hole |
|---|---|
| Termination Style | Pin |
| Buzzer Technology | Piezo |
| Buzzer Type | Transducer |
| Operation Mode | Single Tone |
| Tone | continuous |
| Body Type | Round |
| Sound exit port location | Top |
|---|---|
| Input type | zero-peak |
| Rated Voltage | 12V |
| Operating Voltage Range | 3-28V |
| Mean Current | 10mA |
| Frequency | 2500 ± 500Hz |
| Sound Output Level | 85dB @ 30cm |
| Body Color | Black |
|---|---|
| Operating Temperature | (-20°C to 90°C) |
| Storage Temperature | (-30°C to 100°C) |
| Width | 30mm |
| RoHS | Yes |
| REACH Compliant | Yes |
