Datasheet
Additional information
| Mounting Type | Surface Mount |
|---|---|
| Termination Style | Solder Pads |
| Buzzer Technology | Magnetic |
| Buzzer Type | Indicator |
| Operation Mode | Single Tone |
| Tone | continuous |
| Body Type | Square |
| Sound exit port location | Top |
|---|---|
| Input type | DC |
| Rated Voltage | 5 V |
| Operating Voltage Range | 4 – 7V |
| Mean Current | 30 mA |
| Frequency | 2400 ± 300Hz |
| Sound Output Level | 90dB @ 10cm |
| Body Color | Gray |
|---|---|
| Operating Temperature | (-20°C to 70°C) |
| Storage Temperature | (-30°C to 80°C) |
| Width | 12.6mm x 12.6mm |
| RoHS | Yes |
| REACH Compliant | Yes |
