LED Panel Mount Indicator Red 22mm Round 24V Screw Block IP65

Product Description

PMI 22mm LED 24V Screw Block Flat Red

Technical Downloads:

Datasheet Download
STEP File Download
IGES file Download

Description

MOQ is set to 90 because we get the PCL22 series from a supplier at an odd MOQ, keep the MOQ at 90.

Additional information

ECCN

EAR99

RoHS

Yes

Mounting Hole Dimension

Dia. 22mm

REACH Compliant

Yes

Standard/Custom Product

Standard

Voltage

24 VDC

Lead Time (wks)

12

LED Output Color

Red

Lens Type

Translucent Lens

PMI Color

Red

Lens Shape

Round Lens

MSL Rating

SAP Look Up

Yes

Sub Family

LED Panel Mount Indicator Lights

Terminals

Screw Blocks

Finish

Black

Package Qty

15

PMI Housing Finish

Black Polyamide

Series Name Single Select

PCL22

Minimum Order Qty

90

Package Type

Bulk Bag

PMI Mounting

Front Panel Mounting

Material Lens

Polycarbonate UL 94-V2

Mounting Type

Front Panel Mount

Product Family

VCC

Product Status

New Product Introduction (NPI)

Manufactured By

Buy Resell

Peak Wavelength (nm)

630 nm

Country of Origin

CN (China)

Mounting Hardware

With Lockwasher and Hex Nut

Tab Terminal Size

Harmonization Code

8531.80.90.51

PMI Panel Thickness

0.039" to 0.255"

Degree of Ingress Protection

IP65

Price Book Export Key Attribute for Macro

VCC

Qualifies for Design Registration

Yes

Conflict Mineral Free

Yes

Mounting Hardware Included

Yes

Is this product an NPI?

Yes

In the external Price Book?

Yes
