All Products Panel Mount Indicators LED Panel Mount Indicator CNX 722 120V Series LED Panel Mount Indicator Green 22mm Round 120V Quick Disconnect Terminals IP67

LED Panel Mount Indicator Green 22mm Round 120V Quick Disconnect Terminals IP67

SKU: CNX722C500120T Categories: , ,

Technical Downloads:

Datasheet Download
STEP File Download
IGES file Download

Product Availability

Distributor Stock View in Website

Additional information

RoHS

Yes
Mounting Hole Dimension

Dia. 22mm
REACH Compliant

Yes
Rated Current

8 mA
Voltage

120 Volts
Lamp Type

LED
PMI Color

Green
PMI Shape

Round
Terminals

Tab Terminals – Quick connect
Wire Gauge

18 AWG
Country of Origin

MX (Mexico)
Luminous Intensity Typ. (mcd)

924 mcd
Tab Terminal Size

0.187"
PMI Panel Thickness

Up to 0.300"
Degree of Ingress Protection

IP67
