Datasheet
Additional information
| Mounting Type | Through Hole |
|---|---|
| Termination Style | Pin |
| Buzzer Technology | Piezo |
| Buzzer Type | Indicator |
| Operation Mode | Single Tone |
| Tone | continuous |
| Body Type | Round |
| Sound exit port location | Top |
|---|---|
| Input type | DC |
| Rated Voltage | 12V |
| Operating Voltage Range | 3 – 24V |
| Mean Current | 15mA |
| Frequency | 3800 ± 500Hz |
| Sound Output Level | 95dB @ 30cm |
| Body Color | Black |
|---|---|
| Operating Temperature | (-20°C to 70°C) |
| Storage Temperature | (-30°C to 80°C) |
| Width | 23mm |
| RoHS | Yes |
| REACH Compliant | Yes |
